Cornell - 200-180-700HP

The 200-180-700HP pump is designed with renowned quality and durability. It features a 6” discharge, 8” suction, and a 3 or 4 vane enclosed CA6NM impeller.
Cornell Model: 6822MX

Cornell - 200-180-700HP

The wear rings can be hardened (option) to 375-425 BHN (impeller) and 450-500 BHN (voulte). Patented Cycloseal® design is standard, with a Type 2 single mechanical seal with Buna-N elastomers, stainless steel hardware and tungsten carbide vs. silicon carbide seal faces for abrasion resistance.

Maximum Head (metres)180
Max Flow l/sec200
Solid Handling50

Pump curves of 200-180-700HP


While this pump / equipment matches your duty criteria, other factors may determine the suitability and therefore NPE advise that you contact us to discuss your requirement.
