The BA range of pumps has been designed with a clear focus on reliability, efficiency and durability. Featuring a 100% mechanical priming system, the BA series pumps quickly prime and re-prime, even from dry conditions. The heavy build style of both pump and canopy make the BA range perfect for use in the strenuous contractor market.
World-class performance
The BA range is built to be deployed on the most demanding dewatering and sewage bypassing applications. Using high efficiency pumps and state-of-the-art diesel engines, the pumps offer maximum performance at minimal cost, fully in-sync with the company philosophy of “Lowest cost of ownership”.
KEY FEATURES
- High efficiency pumps minimising fuel consumption
- Corrosion free hot dip galvanised canopy
- Corrosion free composite door panels and powdercoated plating
- 100% Oil-spill free priming system
- Fully bunded unit eliminating fuel/oil spills at all times
Complete package designed & built by BBA Pumps
- Complete in-house design & production
- Over 60 years of experience in the market
- Complete testing facility in-house
- Contemporary & functional design
- Durable & eco-friendly materials
- Custom builds available
PUMP PERFORMANCE CURVE
| Pump Specifications | |
|---|---|
| Pump Specifications Type | BA500G D675 |
| Pump Specifications Max Flow | 1250L/S |
| Pump Specifications Max Pressure | 26mwc |
| Pump Specifications Connections | Discharge DN500 - Suction DN600 |
| Pump Specifications Solids Handling | 4.5" / 115mm |
| Pump Specifications Impellar Type | Axial Flow Impeller |
| Pump Specifications Priming System | BBA MP100 |
| Pump Specifications Engine | Volvo Penta TAD1345VE |
| Pump Specifications Emission Standard | Stage II / Tier 2 |
| Pump Specifications Canopy | EL23-58 |
| Pump Specifications Sound Level | 75dBA at 10m |
| Pump Specifications Dry Weight | 10,900KG |
| BBA Auto Prime Pump | |
|---|---|
| BBA Auto Prime Pump Best Efficiency Point | 87% |
| BBA Auto Prime Pump Pump Casing | Cast Iron GG20 |
| BBA Auto Prime Pump Impeller | Ductile Iron GGG40 |
| BBA Auto Prime Pump Pump Shaft | 42CrV6 |
| BBA Auto Prime Pump Shaft Seal | Mechanical Seal |
| Engine | |
|---|---|
| Engine Engine Brand | Volvo Penta |
| Engine Engine Type | TAD1345VE |
| Engine IFN Power | 368kW (500HP) |
| Engine Rating | IFN Power |
| Engine Fuel Consumption | 200g/kWH |
| Engine Governor Type | Electronic |
| Engine Displacement | 12.78 l |
| Engine Number of Cylinders | 6 |
| Engine Emission Level | Stage II / EPA Tier 2 |
| BBA Sound Attenuating Canopy | |
|---|---|
| BBA Sound Attenuating Canopy Canopy Type | EL23-58 |
| BBA Sound Attenuating Canopy Dimensions L x W x H | 5830 x 2306 x 2300mm |
| BBA Sound Attenuating Canopy Dimensions L x W x H | 229 x 90.8 x 90.5 Inch |
| BBA Sound Attenuating Canopy Basic Frame | Hot Dip Galvanised |
| BBA Sound Attenuating Canopy Doors | 8 Easy-Access Doors (Lockable) |
| BBA Sound Attenuating Canopy Door Panels | ABS/ASA |
| BBA Sound Attenuating Canopy Fuel Tank | PE net 300 ltr. (80US Gallon) |
| BBA Sound Attenuating Canopy Fuel Tank Autonomy | 4 Hours (at 1800RPM BEP) |
| BBA Sound Attenuating Canopy Fuel Tank | 2.5" / 60mm |
| BBA Sound Attenuating Canopy Forklift Pockets | Fitted with 2 Forklift Pockets |
| BBA Sound Attenuating Canopy Lifting Point | Fitted with 4 Lifting Points |
| BBA Sound Attenuating Canopy Oil Drain Pump | Drain Pump for Motor Oil Installed (Hand Pump) |
| BBA Sound Attenuating Canopy Connections | Flange Connections |
| BBA Sound Attenuating Canopy Exhaust System | Intergrated with Canopy |
| BBA Sound Attenuating Canopy Emergency Stop | Applicable |
| BBA Sound Attenuating Canopy Additional | Fitted with Oil-Water Separator |
| BBA Sound Attenuating Canopy Documentation | User Manual & BBA Warranty Book |
