Key Features
- Genuine Japanese Mitsubishi engine
- Genuine Japanese Taiyo alternator
- Full IP56 / IP66 rated outlet kit optional
- Full MCB & RCD protection
- Earth leakage protection
- Fork pocketed bunded skid base
- Quick view control panel(with lighting)
- Remote start/stop controller (Optional)
- Lockable silenced super duty canopy
- Lockable fuel door
- Exhaust Rain Cap
- Certified Australian Standard Wiring
- Certified center lift point
- Certified tie down points
- Compliance plating
- Emergency stop
- Battery isolator
- External servicing drain points
- Fire Extinguisher
- Earth stake
- Operators manual
- 3 way fuel valve (optional)
- Site compliant fleet numbering (optional)
- Solar battery charging (optional)
Generator Specifications
| SPECIFICATIONS | PRIME | PRIME |
|---|---|---|
| SPECIFICATIONS Voltage (V) all options | PRIME 200, 380, 400, 415 | PRIME 200, 380, 400, 415 |
| SPECIFICATIONS Frequency (Hz) / rpm | PRIME 50/1500 | PRIME 60/1800 |
| SPECIFICATIONS Dimensions (mm) | PRIME 3100L x 1200W x 1650H * | PRIME 3100L x 1200W x 1650H * |
| SPECIFICATIONS Dry / operating mass | PRIME 1800 / 2050 (wet) | PRIME 1800 / 2050 (wet) |
| SPECIFICATIONS Sound level *1 (dB/A) | PRIME 91 | PRIME 91 |
| SPECIFICATIONS Pressure level *1 (db/A) | PRIME 61 | PRIME 64 |
| SPECIFICATIONS Class or rating | PRIME Continuous | PRIME Continuous |
engine Specifications
| Manufacturer and Model | ISUZU BB-6BG1T | ISUZU BB-6BG1T | |
|---|---|---|---|
| Manufacturer and Model Cylinders | ISUZU BB-6BG1T 6 Cylinder | ISUZU BB-6BG1T 6 Cylinder | |
| Manufacturer and Model Type - 4 Cycle water cooled | ISUZU BB-6BG1T Direct Injection. Turbo charged, lntercooled | ISUZU BB-6BG1T Direct Injection. Turbo charged, lntercooled | |
| Manufacturer and Model Total Displacement (L) | ISUZU BB-6BG1T 6.494 | ISUZU BB-6BG1T 6.494 | |
| Manufacturer and Model Related Outputs PS (KW) | ISUZU BB-6BG1T 100 (73.6) | ISUZU BB-6BG1T 124 (91.2) | |
| Manufacturer and Model Fuel type and tank capacity | ISUZU BB-6BG1T 225L Diesel Fuel Oil | ISUZU BB-6BG1T 225L Diesel Fuel Oil | |
| Manufacturer and Model Fuel consumption (L/hr) 50 / 75% load | ISUZU BB-6BG1T 10.2 / 14.5 | ISUZU BB-6BG1T 13.2 / 19.0 | |
| Manufacturer and Model Lubricating oil capacity (L) | ISUZU BB-6BG1T 18 | ISUZU BB-6BG1T 18 | |
| Manufacturer and Model Cooling water capacity (L) | ISUZU BB-6BG1T 24 | ISUZU BB-6BG1T 24 | |
| Manufacturer and Model Battery Capacity | ISUZU BB-6BG1T 95D31R(64) x2 | ISUZU BB-6BG1T 95D31R(64) x2 |
Output & Electrical specification
| OUTPUT |
|---|
| OUTPUT Prime 555kVA |
| ELECTRICAL SPECIFICATION | |
|---|---|
| ELECTRICAL SPECIFICATION Power Factor | 0.8 |
| ELECTRICAL SPECIFICATION No. of phases | 3-Phase, 4-Wire |
| ELECTRICAL SPECIFICATION Exciting method | Brushless (with A.V.R) |
