Jumbo Fuel Tanks
Key Features
- Integrated Bunded Pump Bay and Tank Access Platform design providing access to the full tank functionality in one convenient location on the tank
- Unique rounded rectangular tank profile maximises the storage capacity of the tank and provides the strength of a cylindrical design
- Rounded roof profile that will not pool water / snow or sand
- CSC plated as 10ft / 20ft / 40ft / 48ft Standard Container.
- Dispensing Equipment housed within a lockable bunded pump bay housing
- Lockable Container Doors with option for Roller Door
- Supplied with Interstitial Emergency Relief Vent that will relieve the gap between the two tanks in the event of a fire
- DN80 Fill Point c/w Camlock Male Fitting / Dust Cap / Fire Safe Full Bore Ball Valve / Wafer Style Non Return Valve
- DN80 Suction Outlet c/w Anti Syphon Valve and Two Piece Full Bore Fire Safe Ball Valve
- DN80 Mechanical Overfill Valve + 12V Battery Operated Overfill Alarm
- 2 x 600mm manways with integrated tank access ladder assembly
- Fold out AS1657 designed and approved access ladder
- Removable plate to allow the linking of multiple tanks in tank farm applications
- Full under tank visibility allows for regular visual inspect of the tank base and prevents the base rusting by providing for unrestricted air flow under the tank
- Paint Colour RAL9003 Signal White/ Tanks are sandblasted to SA2 Standard. Hempel Marine Paint 3 Stage process. Primer Hempadur 1530. 2nd Coat Hempadur Hi- Build 4520. Final Coat Hempathane Enamel 55100 Finished dry film thickness no less than 180 um
- Supplied with all required statutory safety decals for your region of operation
